GL620/21 Single-Shaft Grinder with Hydraulic Drive
The GL620 with a 620 mm rotor is a single-shaft grinder with a radial pusher and hydraulic drive, capable of ensuring high hourly throughput.
Description
The machine is equipped with a radial pusher: the larger grinding surface allows for high hourly productivity, while the possibility of using a planetary gear reducer and automatic reverse make this machine a high-performance single-shaft grinder.
Technical specifications
-
Monolithic welded structure providing high machine sturdiness.
-
Large grinding surface.
-
Bearings widely separated from the crushing area.
-
Planetary gear reducers.
-
Overall dimensions (mm): 5,100 x 4,200 x H 3,800
-
Cutting chamber (mm): 2,100 x 1,400
MILLS LCB710-24
Lacerators are twin-shaft shredders with special blades specially designed to break up material but not reduce its volume.
- Power 2 x 110 KW
- Grinding body made of electro-welded steelwork
- No. 2 cylindrical shafts with a diameter of 295 mm onto which the Hardox tearing blades are welded
- Screening bench positioned below the blades to adjust the size of the output material
- Loading hopper
- Support base
- Hydraulic drive unit
TWO-SHAFT SHREDDERS TR2A
The twin-shaft shredders of the TR2A series are designed for volumetric reduction and rough shredding of materials such as plastic, paper, cardboard, electrical cables, tyres, etc.
- Installed power: 2x22Kw
- Construction Year 2014 completely overhauled
- Integral blades 30 mm thick
- Cutting chamber length mm 1000
- Including electrical cabinet with possibility of PLC-controlled automatic rotor motion reversal
- Voltage 50Hz
